IEC60884-1 figure 28 Apparatus for Abrasion Test on Insulating Sleeves of Plug Pin

1. Introduction

Apparatus for abrasion test on insulating sleeve of plug pin is designed according to IEC60884-1 figure 28 and BS1363 figure 9, it is applied to test abrasion resistance performance of insulating sleeves of plug pin. The test apparatus is consisted by horizontally placed beam and a linear motion clamp, the U sharp steel wire with diameter of 1mm is vertically fixed at the end of the horizontal beam, the U-shaped bottom edge of the wire is 6mm linear working part, press the U-shaped wire 6mm straight bottom edge on the bolt insulation sleeve, the motor drives the clamp with the pin to back and forth, so that the wire and the insulating sleeves of plug pin to do the abrasion test. After the test,the plug pin shall be free from damage that may affect safety or affect future use, especially the insulating sleeves can not worn or wrinkled.

2. Parameter

3. Figure

4. FAQ

What is the warranty period? and how can we get the after-sales service?

Pego: The warranty period is 12 months upon user receive the goods. 95% of after-sales problems can be solved by our engineer team through remote service. Customers will get a response within 24 hours in business day after reporting the problem. In our experience, most of the troublesome can be removed with the guidance of our engineer, only a small part of the troublesome are caused by parts failure, that is because we use the branded components, which have better performance and good reliability. If the parts damaged, we will a send a new for replace, the new parts will be charged for free within the warranty period. And also our eigneer team will teach how to replace the damaged parts.
