    Luminous Intensity Light Meter Led Lamp Tester 00.1~5000cd/M2 Luminometer For Site Test

    Ask Lasest Price
    Brand Name : PEGO GROUP
    Model Number : PHOTO-200L
    Price : USD300~USD500
    Payment Terms : T/T, MoneyGram
    Delivery Time : 7 working days
    • Product Details
    • Company Profile

    Luminous Intensity Light Meter Led Lamp Tester 00.1~5000cd/M2 Luminometer For Site Test

    00.1~5000cd/m2 Luminometer Luminous Intensity Light Meter for Site Test


    1. Introduction

    The luminometer is applied to test the luminance at site, it adopts high-speed AMR processor and high-precision optical sensor, it has the features of lightweight design, stable performance, high precision and easy to carry. Equipped with 3.5-inch IPS LCD touch screen, making the device only has size of 65mm * 147mm * 18.5mm and weight of 180g. It is widely used in home, shopping mall, school, factory, greenhouse, outdoor and other field lighting measurement fields


    2. Parameter

    ModelPHOTO-200L
    Wavelength range380nm~800nm
    Accuracy of luminanceClass 1 (±4% reading+1 digit)
    liminance measurement range00.1~5000cd/m2
    Interface portType-C
    Sampling time50~10000mS
    Dimension

    65mm*147mm*18.5mm

    screen: 56mm*113mm

    Display area: 50mm*75mm (3.5 inch touch screen)

    Power Supply

    built-in Li-battery (12h standby) and power adaptor

    Charging adapter: AC110V~220V ±10% (input), DC5V/1A±5% (output)

    working condition-10℃~+40℃ / 0~70% R.H.
    Operation languageChinese / English switchable

    3. PHOTO-200 Series

    ModelWavelength rangePeak wavelengthIlluminance/luminance measurement rangeError
    PHOTO200380nm~800nm0.1Lx~1000K LxClass 1 (±4%+1 digit)
    PHOTO200L380nm~800nm0.1~5000cd/m2Class 1 (±4%+1 digit)
    PHOTO200UVC230nm~280nm254nm0.1~20000uW/cm2±5%
    PHOTO200UVA320nm~380nm365nm1~50000uW/cm2±5%
    PHOTO200IR810nm~890nm850nm1~20000uW/cm2±5%
    PHOTO200IR880nm~980nm940nm1~20000uW/cm2±5%
    PHOTO200F

    380nm~800nm

    Frq: 50Hz~250kHz

    0.1Lx~1000K LxClass 1 (±4%+1 digit)


    4. Size and appearance


    5. FAQ
    1). Is the meter suitable for outdoor use?
    Answer: yes, this meter is special for site test.

    2). Is the meter rechargeable?
    Answer: yes, the meter adopts Li-battery which is rechargeable with input voltage 110V~220V.

    3). What is the lead time?
    Answer: generally, the lead time is 7 working days upon we receipt of your payment.
