Test Finger Probe with 125mm Stop Meet the requirement of IEC60335-2-14

Introduction

The test finger probe is designed according to IEC60335, GB4706.1, GB2099.1, IEC61032, UL standard.

Parameters:

1). Finger diameter: 12mm

2). Finger length: 100mm

3). Stop face diameter: 125mm

4). Standard: IEC60335-2-14

Remark: The test probe is identical to test probe B of IEC61032 except that the diameter off a circular stop face is 125mm and a distance between the tip of the test finger and the stop face is 100mm.

Picture:
